| Specification |
Engine Model |
| Model |
255 DI |
275T U |
575 DI |
805 DI |
110 DI |
| Aspiration |
NA |
NA |
NA |
TC |
TCI |
| Bore x Stroke (mm) |
88.9X110 |
88.9X101.6 |
88.9X101.6 |
94X115 |
96X122 |
| No. of Cylinders |
2 |
3 |
4 |
4 |
4 |
| Firing Order |
1-2 |
1-3-2 |
1-3-4-2 |
1-3-4-2 |
1-3-4-2 |
| Engine direction of rotation |
Anti Clockwise |
Anti Clockwise |
Anti Clockwise |
Anti Clockwise |
Anti Clockwise |
| Combustion system |
Direct Injection |
Direct Injection |
Direct Injection |
Direct Injection |
Direct Injection |
| Fuel Injection Pump |
In-Line |
In-Line |
In-Line |
In-Line |
In-Line |
| Rated Speed |
2400 rpm |
2600 rpm |
2300 rpm |
2300 rpm |
2300 rpm |
| Rated Power (Gross) |
24hp |
39hp |
44.5hp |
76hp |
110hp |
| Engine lub oil Grade |
SAE-15W40 |
SAE-15W40 |
SAE-15W40 |
SAE-15W40 |
SAE-15W40 |
| Lub oil normal operating pressure range |
3 to 5 bar |
3 to 5 bar |
3 to 5 bar |
3 to 5 bar |
3 to 5 bar |
| Lube oil Pressure at Idle |
1.5 bar (min) |
1.5 bar (min) |
1.5 bar (min) |
1.5 bar (min) |
1.5 bar (min) |
| Max Torque (Gross) |
77 Nm @1400+/-100 rpm |
118 Nm @1500+/-100 rpm |
157 Nm @1500+/-100 rpm |
280 Nm @1400+/-100 rpm |
402Nm @1500+/-100 rpm |
| Gear Box (Hydrolic) |
MA 100 |
MA 125 |
MA 125 |
MA 125 |
MB 170 |
